Infrared/Visible Light Composite Seeker
The low-cost, small-size roll-yaw dual-mode seeker is suitable for light unmanned aircraft like cruise missiles. It's used to collect target images, receive ground control commands to search and track targets, and output guidance information to the flight control system.
Dual-mode detection (visible light + infrared)
Suitable for day and night use and complex environments Enhanced target recognition reliability
Compact size, ideal for lightweight integration
Dual-mode Target Detection Capability
Unlike single-mode seekers, this system integrates both visible-light and infrared imaging channels. The visible-light sensor provides high-resolution image detail for precise identification, while the infrared sensor enables detection in low-visibility conditions such as darkness, smoke, or heavy fog.The system employs a roll-yaw-stabilized configuration, enabling precise target tracking and smooth operation, and ensuring stable performance in dynamic scenarios.
Dual Imaging Sensors
Equipped with a 1920×1080 color CMOS sensor for visible light imaging and a 640×512 uncooled infrared sensor for thermal imaging detection.
High-Precision Tracking
Azimuth positioning accuracy ≤0.2°, maximum angular velocity ≥60°/s, enabling agile target tracking.
Flexible System Integration
Supports RS232 control interface and network video output for easy system integration.
Designed for Versatile Target Acquisition
This search and detection system provides effective detection and identification capabilities under various environmental conditions. The identification range of the visible light channel reaches ≥2.5 kilometers (for a 6-meter × 4-meter target), while the infrared channel provides a detection range of ≥2 kilometers under similar conditions.
With a wide field of view (visible light: ≥12° × 7°, infrared: 8° × 7°), the system ensures efficient target acquisition and tracking performance.
The system operates within a wide temperature range (-40°C to +60°C) and supports rapid startup (≤15 seconds), ensuring reliability in various operational environments.
Specifications
| Product Name |
Infrared / Visible Light Composite Seeker |
|
power supply
|
9V~18V
|
|
Power Consumption
|
＜20W
|
|
Startup Time
|
≤15s
|
|
Operating Temperature
|
-40℃~+60℃
|
|
Angular Position Accuracy
|
≤0.2°
|
|
Maximum Angular Velocity
|
≥60°/s
|
|
Field of View
|
≥12°×7°（25mm)
|
|
Recognition Distance
|
≥2.5km（6m×4m)
|
|
Field of View
|
8°×7°（35mm)
|
|
Recognition Distance
|
≥2km（6m×4m)
|
Application Scenarios
This multi-mode seeker is suitable for systems requiring flexible, multi-mode detection and tracking.
Dual-mode electro-optical tracking systems UAV payloads Target detection in complex environments Lightweight precision-guided platforms
FAQ
1.What are the advantages of the dual-mode seeker?
It combines visible light and infrared imaging technologies, enabling it to operate effectively in both normal and low-visibility environments.
2. What is the detection range?
Depending on specific conditions, the range can reach up to 2.5 kilometers in visible light mode and up to 2 kilometers in infrared mode.
3. Is it suitable for small drones?
Yes. Its compact size and lightweight design make it ideal for lightweight platforms.
